PELLENC POWER TOOL BATTERY OLIVION +
56_131087-H
3. DESCRIPTION AND TECHNICAL CHARACTERISTICS
3.1. TECHNICAL CHARACTERISTICS - BATTERY
Characteristics of OLIVION + battery
Nominal\battery voltage
43.2 V
Type of battery 12 times 6 elements included in 1 pack
Battery capacity 17.4 Ah
Battery power 752 Wh
Battery life Depending on the tool
Weight of the battery 4.9 kg
Weight of the carrying vest (comfort harness) 1.5 kg
Weight of the carrying vest (light harness) 0.83 kg
Operating frequency bands 13.56 MHz, receiver
3.2. TECHNICAL CHARACTERISTICS - CHARGER
CB5022 Charger Quick charger CB5075 CB5022HV charger
Commercial reference of
the charger
57230 57011 57256
Voltage 100-240V ~ 50/60Hz
140W class II
100-240V ~ 50/60Hz
485W class I
100-240V ~ 50/60W 130W
class II
Charging voltage 50.2 V dc
Charging current 2.2A DC max. 7.6A dc max. 2.2A DC max.
Battery OLIVION +
70% 5 hrs. 30 min.
CB5022 Charger (2.2A)
100% 9 hrs
70% 01:30
Quick Charger CB5075 (7.6 A)
100% 03:15
70% 5 hrs. 30 min.
CB5022HV charger (2.2 A)
100% 9 hrs
Note
If after charging with the CB5075 charger the bat-
tery display indicates less than 95%, the next time
the battery is charged it must be done with the orig-
inal charger.
The sticker shown below is affixed to the CB5075
charger as a visual reminder of this warning.
8
