Peloton ROW User Manual

B
A Power Button
(on back of Touchscreen)
B Volume Control
C Monitor Arm
D Base
E Power Cord
F Wheels
G Power Switch
(under the Base)
H Rowing Handle
I Foot Rest
J Rail Handle
K Rail
L Rail Foot
M Seat
N Heel Slide
O Accessory Tray
P Touchscreen

G
J
L
H F
E
C
I
M
K
O
A
D
P
10
11
|
GETTING TO KNOW YOUR PELOTON ROW
Touchscreen swivels 45 degrees left
and right and 25 degrees up and down.
N

Peloton ROW Specifications

General

Weight	156 lbs
Max User Weight	300 lbs
Connectivity	Bluetooth 5.0
Dimensions	2 ft (24 in) W
Footprint	8 ft x 2 ft
Power Requirements	100-240V ~50/60Hz
User Height Range	4'11" - 6'5"
Display	23.8-inch HD touchscreen
