14
Using a suitable attachment to your car (bike rack), you can
always transport your Pedelec in the same way as a bicycle.
• Note: as the Pedelec weighs more than a normal bicycle,
your bike rack must meet the proper requirements.
9. Transporting your
Pedelec
9.1 By car
9.2 Using public transport
Take the battery o prior to transport, and always
store it seperately during transport.
Here, the same rules apply as when transporting a bicycle.
For safety reasons, remove the battery from your Pedelec
when boarding a bus or train, and replace it when the jour-
ney is over.
9.3 By airplane
In this case, the battery must be declared for transport as
dangerous freight. The battery must be labeled as such. Ask
your air transport company for advice.
10. Disposal
eMachine, battery, electronic bottom bracket, wheel speed
sensor, component parts and packaging should always
be recycled or disposed in a way compatible with the
environment.
Do not dispose of your Pendix motor or Pendix
components in domestic waste containers!
In accordance with European Directive
2002/96/EU, usable electrical equipment
must no longer be disposed through normal
channels, and in accordance with the European
Directive 2006/66/EU, defective or
used batteries must be collected separately
and be disposed in an environmentally safe
recycling system. Always return batteries
that are no longer usable to your authorized
bicycle salesman/ technician.
11. Technical data
eMaschine
motor
gearless mid-mounted
motor
performance 250 W nominal
speed (max) 25 km/h
motor settings up to 3
torque (max)
32 Nm (eDrive150)
65 Nm (eDrive300/500)
sound pressure level
Lpmax in dB(A)
passing through with
motor
45.1
starting with motor
49.0
ePower500
type Lithium-Ionen 13S3P
capacity 497 Wh nominal
voltage (norm) 48 V
distance (max)* 62 - 120 km
overall system
system weight 5.8 kg (eDrive150)
6.9 kg (eDrive300)
7.3 kg (eDrive500)
operating temperature -10° C to +50° C
storage temperature -20° C to +60° C
tightening torque values for screw connections
battery holder on the
frame (with safety screws)
4.5 Nm ± 0.5 Nm
electronic bottom bracket
right-hand assembly
side (greased)
15 Nm
± 2 Nm
bottom bracket mounting
(greased)
65 Nm
± 3 Nm
crank screw le/right
(with safety screws and
grease on square sha)
32 Nm
± 2 Nm
pedal le/right 35 Nm
± 2 Nm
connector cover to
battery holder
2.4 Nm
± 0.2 Nm
chain wheel screws, steel 9 Nm
± 2 Nm
ePower300
type Lithium-Ionen 13S2P
capacity 331 Wh nominal
voltage (norm) 48 V
distance (max)* 41 - 79 km
dimensions (width x height x depth)
ePower150 (Akku) 80 x 190 mm
ePower300 (Akku) 80 x 276 mm
ePower500 (Akku) 80 x 342 mm
eMaschine 292 x 206 x 50 mm
ePower150
type Lithium-Ionen 13S1P
capacity 140 Wh nominal
voltage (norm) 48 V
distance (max)* 13 - 28 km
*the generated riding profile "performance" (factory set-
tings) data is depending on parameters as total weight, dri-
ving behavior, topography, pedaling cadence and bike type
