PressureMAT User Guide
Revision 1
Page 11/29
Keypad
KEY
Function
HOME/START Dual Purpose:
1- Used to return to the HOME screen from the
program menus
2- Used to power on the system if turned off
STOP Used to reset alarms (if optional alarm is latching
turned On)
LEFT ARROW Dual Purpose:
1- Used when in the program menu to scroll
the cursor left
2- Zero pressure sensor of selected channel
when on the HOME screen
RIGHT ARROW Used when in the program menu to scroll the cursor
left
UP ARROW Three Purposes:
1- When on the HOME screen used to select
different input channels
2- In the program menus, used to select
different sub-menus
3- Within a program menu, used to change a
selected value
DOWN ARROW Three Purposes:
1- When on the HOME screen used to select
different input channels
2- In the program menus, used to select
different sub-menus
3- Within a program menu, used to change a
selected value
SELECT/PROG Used to enter the program menu for the selected
channel or for the selected menu
BACK Dual Purpose:
1- Used to return to the previous screen when
in a program menu
2- Can be pressed three times to access the
GLOBAL SETTINGS menu
