i10 0 Door closed consecutive time for
energy saving
0 min to 999 min
After regulation temperature <
SP
0 = Disabled
i13
180
Number of door openings for defrost
0 to 240
0 = Disabled
i14 32 Door open consecutive time for
defrost
0 min to 240 min
0 = Disabled
PAR.
DEF.
ENERGY SAVING (if r5 = 0)
MIN. - MAX.
HE2
0
Energy saving maximum duration
0 min to 999 min
0 = Until the door opening
HE3
2
No operation on the keyboard
consecutive time for low
consumption
0 min to 240 min
0 = Disabled
PAR. DEF. SAFETIES MIN. - MAX.
POF 1 Enable ON/STAND-BY key 0 = No 1 = Yes
PAS 0 Password -99 to 999
0 = Disabled
8
ALARMS
COD.
DESCRIPTION
RESET
REMEDIES
Pr1
Cabinet probe alarm
Automatic
- Check P0
Pr2
Auxiliary probe alarm
Automatic
- Check probe integrity
- Check electrical connection
AL Low temperature alarm Automatic Check A1
AH High temperature alarm Automatic Check A4
id Open door alarm Automatic Check i0 and i1
COH
High condenser temperature
warning
Automatic Check C6
CSd
High condenser temperature
alarm
Manual
- Switch the device off and on
- Check C7
iA
Multi-purpose input alarm
Automatic
Check i0 and i1
dFd Defrost timeout alarm Manual - Tap any key
- Check d2, d3, and d11
9
ELECTRICAL
RATINGS
Output
Units
cULus (UL 60730)
CE (EN 60730)
Applied voltage at 60 Hz
120 VAC
240 VAC
240 VAC
K1
compressor
relay
Resistive amperes
12
12
10
Inductive amperes
—
—
2
Full load amperes
10
10
—
Locked rotor amperes
60
60
—
K2 relay
Resistive amperes
8
8
5
Inductive amperes
—
—
2
Full load amperes
4.4
2.9
—
Locked rotor amperes
26.4
17.4
—
K3
evaporator
fan relay
Resistive amperes
5
5
5
Inductive amperes
—
—
1
Full load amperes
1.5
1.5
—
Locked rotor amperes
9
9
—
10
TECHNICAL SPECIFICATIONS
Purpose of the control device
Function controller
Construction of the control device
Built-in electronic device
Container
Black, self-extinguishing
Category of heat and fire resistance
D
Measurements 2 15/16 in. x 1 5/16 in. x 2 5/16 in. (75 mm
x 33 mm x 59 mm)
Mounting methods for the control device Fit the controller to a panel with the snap-in
brackets supplied
Degree of protection provided by the
covering
IP65 in front
Connection method Fixed screw terminal blocks for wires up to
2.5 mm²
Maximum permitted length for connection cables
Power supply: 32.8 ft (10 m)
Analog inputs: 32.8 ft (10 m)
Digital inputs: 32.8 ft (10 m)
Digital outputs: 32.8 ft (10 m)
Operating temperature
From 32°F to 131°F (from 0°C to 55°C)
Storage temperature
-13°F to 158°F (-25°C to 70°C)
Operating humidity Relative humidity without condensate from
10% to 90%
Pollution status of the control device
2
Compliance
Europe
JCI declares product compliance meets requirements of EMC, LVD, and RoHS
Directives.
USA
UL Recognized Component, SDFY2.SA516; FCC Part 15 Subpart B Class A
Canada
UL Recognized Component, SDFY8.SA516; ICES-003 Class A
Power supply
TC3B23N5x
115 VAC (+10% -15%), 50/60 Hz (+/- 3Hz), max. 2 VA
TC3B23N7x
230 VAC (+10% -15%), 50/60 Hz (+/- 3Hz), max. 2 VA
Grounding methods for the control device None
Rated impulse-withstand voltage 4 KV
Over-voltage category III
Software class and structure A
Analog inputs 2 for NTC probes (cabinet probe and auxiliary
probe)
NTC probes
Sensor type
ß3435 (10 K
Ω
at 77°F, 25°C)
Measurement field
From -40°F to 221°F (from -40°C to 105°C)
Resolution
1°F (0.1°C)
Digital inputs
1 dry contact (door switch/multi-purpose)
Dry contact
Contact type
5 VDC, 1.5 mA
Power supply
None
Protection
None
Digital outputs
3 electro-mechanical relays (compressor, defrost and evaporator fan)
Type 1 or Type 2 actions
Type 1
Additional features of Type 1 or Type 2
actions
C
Displays 3 digits custom display with function icons
11
PRODUCT WARRANTY
This product is covered by a limited warranty, details of which can be found at
www.johnsoncontrols.com/buildingswarranty
12
SOFTWARE TERMS
Use of the software that is in (or constitutes) this product, or access to the cloud, or hosted
services applicable to this product, if any, is subject to applicable end-user license, open-
source software information, and other terms set forth at
www.johnsoncontrols.com/techterms
. Your use of this product constitutes an agreement to such terms.
13
SINGLE POINT OF CONTACT
APAC
Europe
NA/SA
JOHNSON CONTROLS
C/O CONTROLS PRODUCT
MANAGEMENT
NO. 32 CHANGJIJANG RD NEW
DISTRICT
WUXI JIANGSU PROVINCE
214028
CHINA
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
14 CONTACT INFORMATION
Contact your local branch office:
www.johnsoncontrols.com/locations
Contact Johnson Controls:
www.johnsoncontrols.com/contact-us
Important
The device must be disposed of according to local regulations governing the collection
of electrical and electronic waste.
This document and the solutions contained therein are the intellectual property of Penn and thus
protected by the Italian Intellectual Property Rights Code (CPI). Penn imposes an absolute ban on the
full or partial reproduction and disclosure of the content other than with the express approval of Penn.
The customer (manufacturer, installer or end-user) assumes all responsibility for the configuration of the
device. Penn accepts no liability for any possible errors in this document and reserves the right to make
any changes, at any time without prejudice to the essential functional and safety features of the
equipment.
Johnson Controls
507 E. Michigan St.
Milwaukee, WI 53202-5211
USA
www.penncontrols.com
