PENN | TC3B23 | Installation Guide Rev. B | Part No. 24-7664-03574 | Page 2 of 2 | 07 April 2020
N. PAR. DEF. DIGITAL INPUTS MIN... MAX.
53 i0 1 door switch/multi-purpose input
function
0 = disabled
1 = compressor + evapora-
tor fan off
2 = evaporator fan off
3 = energy saving
4 = iA alarm
5 = iA alarm + compressor
off
54 i1 0 door switch/multi-purpose input
activation
0 = with contact closed
1 = with contact open
55 i2 30 open door alarm delay -1... 120 min
if i0 = 3, multi-purpose input
alarm delay
if i0 = 4, compressor on de-
lay after alarm reset
-1 = disabled
56 i3 15 regulation inhibition maximum
time with door open
-1... 120 min
-1 = until the closing
57 i10 0 door closed consecutive time for
energy saving
0... 999 min
after regulation temperature
< SP
0 = disabled
58 i13 180 number of door openings for de-
frost
0... 240
0 = disabled
59 i14 32 door open consecutive time for
defrost
0... 240 min
0 = disabled
N. PAR. DEF. ENERGY SAVING (if r5 = 0) MIN... MAX.
60 HE2 0 energy saving maximum duration 0... 999 min
0 = until the door opening
61 HE3 2 no operation on the keyboard
consecutive time for low con-
sumption
0... 240 min
0 = disabled
N. PAR. DEF. SAFETIES MIN... MAX.
62 POF 0 enable ON/STAND-BY key 0 = no 1 = yes
63 PAS -19 password -99... 999
8 ALARMS
COD. DESCRIPTION RESET REMEDIES
Pr1 cabinet probe alarm automatic - check P0
Pr2 auxiliary probe alarm automatic - check probe integrity
- check electrical connection
AL low temperature alarm automatic check A1
AH high temperature alarm automatic check A4
id open door alarm automatic check i0 e i1
COH
high condenser temperature
warning
automatic check C6
CSd
high condenser temperature
alarm
manual - switch the device off and on
- check C7
iA multi-purpose input alarm automatic check i0 and i1
dFd defrost timeout alarm manual - touch any key
- check d2, d3 and d11
9 ELECTRICAL RATINGS
Output
Units cULus (UL 60730) CE (EN 60730)
Applied voltage at 60 Hz 120 VAC 240 VAC
240 VAC
K1
compressor
relay
Resistive amperes 12 12 10
Inductive amperes — — 2
Full load amperes 10 10 —
Locked rotor amperes 60 60 —
K2 relay
Resistive amperes 8 8 5
Inductive amperes — — 2
Full load amperes 4.4 2.9 —
Locked rotor amperes 26.4 17.4 —
K3
evaporator
fan relay
Resistive amperes 5 5 5
Inductive amperes — — 1
Full load amperes 1.5 1.5 —
Locked rotor amperes 9 9 —
10 TECHNICAL SPECIFICATIONS
Purpose of the control device Function controller
Construction of the control device Built-in electronic device
Container Black, self-extinguishing
Category of heat and fire resistance D
Measurements
75.0 x
33.
0 x 59.0 mm (2 15/16 x 1 5/16 x
2 5/16 in)
Mounting methods for the control device
T
o
be fitted to a panel, snap-in brackets pro-
vided
Degree of protection provided by the cover-
ing
IP65 (front)
Connection method
Fi
xed screw termi
nal blocks for wires up to
2,5 mm²
Maximum permitted length for connection cables
Power supply: 10 m (32.8 ft) Analog inputs: 10 m (32.8 ft)
Digital inputs: 10 m (32.8 ft) Digital outputs: 10 m (32.8 ft)
Operating temperature From 32 to 131 °F (from 0 to 55 °C)
Storage temperature From -13 to 158 °F (from -25 to 70 °C)
Operating humidity
R
e
lative humidity without condensate from
10 to 90%
Pollution status of the control device 2
Compliance
Europe
JCI declares product compliance meets requirements of EMC, LVD, and RoHS
Directives.
USA UL Recognized Component, SDFY2.SA516; FCC Part 15 Subpart B Class A
Canada UL Recognized Component, SDFY8.SA516; ICES-003 Class A
Power supply
TC3B23N5V 115 VAC (+10% -15%), 50/60 Hz (+/- 3Hz), max. 2 VA
TC3B23N7V 230 VAC (+10% -15%), 50/60 Hz (+/- 3Hz), max. 2 VA
Grounding methods for the control device None
Rated impulse-withstand voltage 4 KV
Over-voltage category III
Software class and structure A
Analog inputs
2 for NT
C probes (
cabinet probe and auxiliary
probe)
NTC probes Sensor type ß3435 (10 K @ 77 °F, 25 °C)
Measurement field From -40 to 221 °F (from -40 to 105 °C)
Resolution 1 °F (0.1 °C)
Digital inputs 1 dry contact (door switch/multi-purpose)
Dry contact Contact type 5 VDC, 1.5 mA
Power supply None
Protection None
Digital outputs 3 electro-mechanical relays (compressor, defrost and evaporator fan)
Type 1 or Type 2 Actions Type 1
Additional features of Type 1 or Type 2 ac-
tions
C
Displays 3 digits custom display, with function icons
11 PRODUCT WARRANTY
This product is covered by a limited warranty, details of which can be found at
www.johnsoncontrols.com/buildingswarranty
12 SOFTWARE TERMS
Use of the software that is in (or constitutes) this product, or access to the cloud, or hosted
services applicable to this product, if any, is subject to applicable terms set forth at
www.johnsoncontrols.com/techterms. Your use of this product constitutes an agreement to
such terms.
13 SINGLE POINT OF CONTACT
APAC Europe NA/SA
JOHNSON CONTROLS
C/O CONTROLS PRODUCT
MANAGEMENT
NO. 32 CHANGJIJANG RD NEW
DISTRICT
WUXI JIANGSU PROVINCE
214028
CHINA
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
14 CONTACT INFORMATION
Contact your local branch office:
www.johnsoncontrols.com/locations
Contact Johnson Controls:
www.johnsoncontrols.com/contact-us
Import
ant
The device must be disposed of according to local regulations governing the collection
of electrical and electronic waste.
This document and the solutions contained therein are the intellectual property of PENN and thus pro-
tected by the Italian Intellectual Property Rights Code (CPI). PENN imposes an absolute ban on the full or
partial reproduction and disclosure of the content other than with the express approval of PENN. The
customer (manufacturer, installer or end-user) assumes all responsibility for the configuration of the de-
vice. PENN accepts no liability for any possible errors in this document and reserves the right to make
any changes, at any time without prejudice to the essential functional and safety features of the equip-
ment.
