6 V46 Series 2-Way Pressure-Actuated Water-Regulating Valves With Union Fittings Installation Instructions
Technical Data
Product V46 Series 2-Way Pressure-Actuated Water-Regulating Valves
Body Material 1/2-in. and 3/4-in. Sizes - Cast Brass Bodies;
1-in. and 1-1/4-in. Sizes - Cast Iron Bodies with Rust-Resisting Finish
Extension Sleeve, Disc,
Stud, Disc Holder Material
Brass
Valve Seat Material Aluminum Bronze
Valve Disc Buna-N
Diaphragm
Nylon Reinforced Buna-N
Water Supply Pressure 150 psig (1034 kPa) Maximum
Water Supply Temperature
170
°
F (77
°
C) Maximum
Water Flow
See Figures 4-7.
Sensing Element Brass and Phosphor Bronze Bellows in Brass Cup
Pressure Range See Table 2.
Shipping Weight
See Table 3.
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, contact Refrigeration Application Engineering at 1-800-275-5676. Johnson Controls shall not be liable for damages resulting
from misapplication or misuse of its products.
Building Technologies & Solutions
507 E. Michigan Street, Milwaukee, WI 53202
® Johnson Controls and PENN are registered trademarks of Johnson Controls in the
United States of America and/or other countries. All other trademarks used herein are the property of
their respective owners. © Copyright 2018 by Johnson Controls. All rights reserved.
