Pentair CC100 User Manual

Rev. D 6-26-09 7 P/N 178556
SECTION IV. TECHNICAL DATA
(1) One GPM per sq. ft. shown, recommended flow rate for residential is .5 GPM per sq. ft.
(2) Commercial flow rate is a maximum of .375 GPM per sq. ft. of filter area.
NOTE: Actual system flow will depend on plumbing size and other system components.
B. Flow Rate Table
A. Filter Pressure Loss Chart
laitnediseR
egdirtraCmumixaM
setaRwolF
laicremmoC
egdirtraCmumixaM
setaRwolF
#tcudorP.tf.qsMPGHPGruoh6ruoh8MPGHPGruoh6ruoh8
4130610505000,3000,81000,4291041,1048,6021,9
5130615757005,4000,72000,6382086,1080,01044,31
613061001001000,6000,63000,8483082,2086,31042,81
713061051051000,9000,45000,2765063,3061,02088,62
813061002051000,9000,45000,2757005,4000,72000,63
C. Replacement Parts
Item Part Number Description
198209800High Flow
™
manual air relief valve
2190058Pressure Gauge
3178553Lid, 50, 100 sq. ft. filter
4178561Lid, 75,150, 200 sq. ft. filter
559052900Locking Ring assy.
687300400Body O-ring
759016200Air Bleed Sock Kit
859053500Center Core, 50 sq. ft. filter
959053600Center Core, 75 sq. ft. filter
10 59053700 Center Core, 100 sq. ft. filter
11 59053800 Center Core, 150, 200 sq. ft. filter
12 R173213 Cartridge Element, 50 sq. ft. filter
13 R173214 Cartridge Element, 75 sq. ft. filter
14 R173215 Cartridge Element, 100 sq. ft. filter
15 R173216 Cartridge Element, 150 sq. ft. filter
16 R173217 Cartridge Element, 200 sq. ft. filter
17 178562 Bottom, 50 sq. ft. filter
18 178554 Bottom, 75 sq. ft. filter
19 178563 Bottom, 100 sq. ft. filter
20 178560 Bottom, 150, 200 sq. ft. filter
21 86202000 Drain Cap Assy.
22 51005000 Drain Cap Gasket
23 39104500 Union Nut “C” Clip
24 98212200 Union Nut
25 071426 Union O-ring
26 79304600 Body, Swivel
3, 4
8, 9, 10, 11
12, 13, 14, 15, 16
17, 18, 19, 20
5
6
7
1
2
21, 22
25
26
24
23
FLOW (gpm)
PRESSURE LOSS (psi)
PRESSURE LOSS vs FLOW
020406080100120140
0
1
2
3
4
5
6
7
8
9
