MagicFalls with LightCascade Technology LED Light Installation and User’s Guide
12
INSTALLING THE MAGICFALLS
®
WITH LIGHTCAS-
CADE
Figure 1. Preparing the Niche.
1. Preparing the Niche for the MagicFalls Water Effects see Figure 1.
Notch the bond beam as shown (Figure 1). Attach a board to the side of the pool
as shown. Make sure this board is level. The board will be used to set the level of
the waterfall and create a form for the mortar bed.
NOTE: WATERFALL LIP IS DESIGNED TO EXTEND OVER AN 8” BOND
BEAM BUT MAY BE PUSHED FORWARD OR BACKWARD DEPENDING
UPON TYPE AND THICKNESS OF WATERLINE TILE. THE LEADING EDGE
OF THE WATERFALL NEEDS TO CLEAR THE FACE OF THE TILE LINE
BY ¾”.
