Pentair Pentek Intellidrive XL User Manual

Appendix A – Manual Sleep Setup 11
A6
When the system stabilizes, record the hp
displayed in the upper left corner.
22-35 Low Speed Power = ________
A7
Slowly scroll up the speed (Hz) until a
maximum safe pressure is achieved.
Record the Speed (Hz) that the drive is
running at and the hp displayed in the
upper left corner.
22-37 High Speed Hz = ___________
22-39 High Speed Power = ________
A8
Press Off.
A9
Quick
Menu
OK
To SmartStart
A10
To Next Step
