Pentair Pentek Intellidrive User Manual

Table 9 (continued)
Menu
Settings
Parameter
Unit of
Measure
Value
Description
Default Min Max
Setpoints
Internal
Setpoint
kPa 414 kPa 103 kPa
668 kPa
(Max
Sensor
Value
minus
30 kPa)
Main pressure setpoint used. Sets
main system operational pressure.
This parameter is accessed here,
through PSI Preset button, or by
pressing Enter button while in
Constant Pressure operation.
External
Setpoint
kPa 276 kPa 103 kPa
Max
Sensor
Value
minus
20 kPa.
Second pressure setpoint. When
another pressure setting is desired
other than Internal Setpoint.
Additional programming needed in
I/O section. Requires an external
switch or timer to wired to I1or
I2 terminals. It is only active
when there is voltage present
I1terminals (see Figure 11)
Sub Menu Parameter
Unit of
Measure
Default Max Min Description
Motor
Motor Phase _ 1 3 1
Selects phase of motor to be
operated. An additional sub menu
will appear, based on phase
selection, to select proper motor
type.
Connection
Type
– 3 wire 3 wire 2 wire
Wire type for 1 phase motor
operation only. Can only access
by first setting Motor Phase
parameter to 1 Phase.
Motor Type – Subm Subm
Above
Gnd
Motor type for 3 phase, 220V,
motor operation only. Can only
access by first setting Motor Phase
parameter to 3 Phase.
Service Factor
Amps
A 00.0 A 00.0 A
Per
drive
and
motor
Service factor amps (max. load) of
motor the Drive is operating. Sets
maximum allowed amps at output
of Drive. See Table 7 for values.
Min Frequency Hz 30 Hz 30 Hz
1 below
Max Hz
Minimum frequency (speed) motor
will run.
Max
Frequency
Hz 50 Hz
1 above
Min Hz
Hz
Maximum frequency (speed) motor
will run.
Sensor
Max Sensor
Value
kPa 689 kPA
2068
kPa
68 kPa
Maximum pressure value of
transducer sensor used with Drive.
Only change if different transducer
is used with Drive, other than 689
kPA max scale.
Programming 14
PID_OM_2014.indd 14 24/02/2014 1:49:57 PM
