Table 9 (continued)
Menu or
Sub Menu
Parameter
Unit of
Measure
Value
Description
Default Min Max
Ex Runtime
Excessive
Runtime
Detection
_ Enabled
Disabled Enabled
Enables or disables Excessive
Runtime Detection.
Excessive
Runtime
Hours
Hours 24 1 100
Number of hours Drive can run
before it faults on Excessive
Runtime.
Dry Run
Auto Restart
Delay
Minutes 10 Min 3 Min 60 Min
Time Drive waits to restart pump
when Dry Run is detected.
Number of
Resets
– 3 0 5
Number of tries Drive attempts
to restart pump when Dry Run
condition is detected.
Detection
Time
M:SS 15 Sec 5 Sec 10 Min
Time the Drive takes to recognize
Dry Run condition.
Sensitivity kPa 68 kPA 0
2068
kPa
Pressure value that Dry Run
condition is detected at. Dry Run
fault will occur if this pressure
cannot be met within Detection
Time window. Lower pressure =
less sensitivity.
Fill Time M:SS 1 M 15 S 10 M
Time allowed to fill (prime) pipes
during Auto Line Fill process.
Relates to Dry Run Sensitivity
value. (Time starts after 55 Hz is
reached).
I/O
Digital Input 1
– Unused – –
Selects operation of Drive when
terminal I1 is used. Select between
Unused, Run Enabled, Ext Fault,
and Setpoint. The Drive will
respond to selected command
when voltage is present at I1
terminal.
Digital Input 2
Relay Output – Unused – –
Selects the operation of Drive
when terminal O1 is used. Select
between Unused, Run, and Fault.
The Drive closes the Relay when
Run or Fault is selected.
Over
Press
Over Pressure kPa 552 kPa
103
kPa
2047
kPa
Sets Over Pressure Warning value.
Change if higher than 552 kPa
system pressure is needed.
No Ground
No Ground
Detection
– Enabled Disabled Enabled
Selects whether Ground Detection
parameter is Enabled or Disabled.
If Disabled is selected, it will revert
back to Enabled after 72 hours.
Warning LED will flash entire time
it is Disabled.
Reset
Factory Reset – No No Yes
Resets all parameters to factory
defaults. Displays Setup Guide
after it is complete. Software
version displayed here. Does not
clear fault log.
SW
Update
Software
Update
– Disabled
Disabled Enabled
Used to update software, if
necessary.
Programming 15
PID_OM_2014.indd 15 24/02/2014 1:49:57 PM
