Pentair Pentek Intellidrive - Installation - Sizing and Mounting; Circuit Breaker and Wire Sizing

Installation 6
Table 2 - Circuit breaker and wire sizes
Motor
Drive
Model
Volts Motor HP
Wire Size*
Circuit
Breaker**
Generator
(kVA)***
Input Output
2-wire PID20
230
1-1/2 2.5mm² 2.5mm²
25 (with RCD,
Ref page2 )
5.3
3-wire
PID20
1-1/2
2.5mm² 2.5mm²
25 (with RCD,
Ref page2 )
5.3
2 5.8
* Wiring size will change depending on the length of wire. See Table 3
** With properly-sized circuit breakers, the Drive is protected from short circuit on the input and the
output. There is no risk of fire or electrical shock due to a short circuit. The Drive has NEC Class 10
overload protection.
*** Minimum 240V generator size.
NOTICE Information in Table 3 applies ONLY to PENTEK
®
motors. For other motors, refer to motor
manufacturer specifications for wire sizing.
Table 3 - Wire Sizing, Drive to Pentek 3-Wire, 1-Phase Motor, 40°C Ambient, and 5 percent Voltage
Drop, 60C and 75C Insulation (copper only).
Motor P/N
Motor Rating Maximum Cable Length in M
Volts HP SFA 1.5 mm² 2.5 mm² 4.0 mm² 6 mm² 10 mm² 16 mm²
G43A0010B2
230
1 6.4 64 117 188 280 305 -
G43A0015B2 1 1/2 9.4 43 80 128 190 305 -
G43A0020B2 2 12.4 33 60 95 140 240 305
