Ready to use everywhere – very easy to install
Technical features
Technical features
Where to locate
At home, in a shop or in an office, the ceiling alarm is immediately ready to use. The built-in passive
infrared motion detector (PIR) reacts to body heat. The alarm is activated as soon as somebody enters
the PIR range. The ceiling alarm can easily be switched on and off with the remote control. Use the
ceiling alarm to secure rooms. The unit is powered by batteries, but can also be powered using a mains
adapter.
alarm unit remote control 2 screws mounting
(battery included) 2 pegs
Power supply: 4 x C batteries (alkaline) 1,5V (LR 14) or
mains adapter 9V, (inner pole of the plug negative)
Power consumption: 1,5 mA (stand-by), 120 mA (alarm)
Sensor: Passive infrared motion detector (PIR)
PIR range: 360° over a diameter of approx. 6 m (mounting height 2,5 m)
Alarm siren: piezo alarm 100 dB(A)
Control system: Infrared remote control
Field of application: Use only in dry locations, protect unit from moisture and frost.
Operating temperature: 0°C – 30°C, Optimal function at room temperature (20°C). Very high or
low temperatures can be detrimental to the function of the unit,
especially when battery operated.
Type: Infrared Ch. B
Power supply: 1 x 12V battery, type 23 A (lighter cell)
Additional remote controls (FB02) are obtainable.
Look for a suitable place on the ceiling. Optimal
function is at a height of 2,5 m.
Locate the unit at a place where most of the
movements are transverse to the PIR. These
movements can be detected more quickly than
movements towards the PIR (Fig. 1).
The unit should not be exposed to direct sun light or
artifical light as this can cause false alarms and reduce
Alarm unit DA02
Remote control FB02
!
!
!
min. 200 mA
(Art.Nr. 32108)
GB
connection for
mains adapter
green LED
red LED
receiver for
remote control
red
LED
ON/OFF
button
less
sensitive
sensitive
fig. 1
2,5 m
6m
fig. 2
