- 24 -
(1) INTERNAL CHANNEL
The illustration above shows the actual routes taken by air, water, and suction through single biopsy/instrument
channel PENTAX videoscopes with forward optics.
EG-290Kp/EC-380Kp
Water Feeding Channel
Air/Water Valve
Channel Inlet
Rubber Inlet Seal
Suction Valve
Suction Tube
Air Feeding Tube
Water Bottle
Water Feeding Tube
Suction Source
Video Processor
Air Feeding Channel
Instrument Channel
Air/Water Nozzle
