Pentax OPTIO S4 Connection Manual

12
1 Double-click the [Unplug or
eject hardware] icon in the task
bar recognized area.
The [Remove Hardware] screen will
appear.
2 Confirm that [PENTAX USB
DISK Device] is selected and
click [Stop].
The [Stop Hardware Device] screen
will appear.
3 Confirm that [PENTAX USB
DISK Device] is selected and
click [OK].
A message will appear.
4 Click [OK].
5 Turn off the camera and
disconnect the USB cable from
your camera and PC.
Disconnecting the Camera from your PC
Windows 2000 / Me
The computer is downloading the camera’s image data with the
camera is connected to the computer and the camera flash status
lamp (red) is flashing. Image data may be damaged if you disconnect
the camera during such conditions.
In the event that an error message is displayed in Step 4, confirm that
the flash status lamp has turned off and then disconnect the camera.

Pentax OPTIO S4 Specifications

Operating Environment

operating temperatures	32˚ to 104˚F (0˚ to 40˚ C)
camera casing	Aluminum alloy

Power

power source	Rechargeable lithium-ion D-LI8 battery, AC adaptor kit (optional)

Camera

effective pixels	4.0 megapixels
total pixels	4.23 megapixels
color depth	10 bit x 3 colors

Lens and Focus System

focal length	5.8mm- 17.4mm
35mm equivalent	35mm-105mm
aperture range	f2.6- f4.8

Viewfinder and Monitor

optical viewfinder	Actual Image zoom viewfinder
lcd monitor	1.6 inch, TFT color LCD with Histogram Display
lcd resolution	84K Pixels

Weight and Dimensions

dimensions	3.3 x 2.0 x 0.8 Inches (83 x 52 x 20mm)
weight without battery and SD card	3.5 oz (98g)
weight loaded and ready	4.1 oz (115g)
