Pentax OPTIO S4 Connection Manual

5
The procedures for installing the necessary software are explained.
1 Turn on your computer.
2 Insert the CD-ROM (S-SW14) into your CD-ROM drive.
The PENTAX Software Installer screen will appear.
3 Click your applicable
language.
You can choose the language from
the following: English, French,
German, Spanish, Italian, Japanese
and Chinese.
4 Click the [USB Driver] on the
Software Installer screen.
The InstallShield Wizard screen will
appear.
Follow the instruction on the screen.
Complete InstallShield Wizard
screen will appear.
Installing the software
If you are using Windows 2000 or Windows XP (Professional),
Please Login as an administrator user before starting installation.
Refer to your PC’s operating manual for instructions on how to login.
• If the PENTAX Software Installer screen is not displayed
Follow the procedure below to display the screen.
1) Double click the [My Computer] icon on the desktop.
2) Double click the [CD-ROM Drive (S-SW14)] icon.
3) Double click the [Setup.exe] icon.
Installing the USB Driver

Pentax OPTIO S4 Specifications

Operating Environment

operating temperatures	32˚ to 104˚F (0˚ to 40˚ C)
camera casing	Aluminum alloy

Power

power source	Rechargeable lithium-ion D-LI8 battery, AC adaptor kit (optional)

Camera

effective pixels	4.0 megapixels
total pixels	4.23 megapixels
color depth	10 bit x 3 colors

Lens and Focus System

focal length	5.8mm- 17.4mm
35mm equivalent	35mm-105mm
aperture range	f2.6- f4.8

Viewfinder and Monitor

optical viewfinder	Actual Image zoom viewfinder
lcd monitor	1.6 inch, TFT color LCD with Histogram Display
lcd resolution	84K Pixels

Weight and Dimensions

dimensions	3.3 x 2.0 x 0.8 Inches (83 x 52 x 20mm)
weight without battery and SD card	3.5 oz (98g)
weight loaded and ready	4.1 oz (115g)
