Pentax OPTIO S4 Connection Manual

14
Viewing Images on a Macintosh
You can use the provided USB cable (I-USB7) or a card reader to
transfer your digital camera’s images to the PC, and you can edit and
print your images using the image viewing software. Here, the
method for viewing images with the provided software (S-SW14) is
explained.
The following software is included in the CD-ROM (S-SW14) provided.
• Image viewing / editing software (ACDSee™)
• OS: Mac OS 9.0 or higher
(requires QuickTime 6.0 or higher)
• CPU: PowerPC 266MHz or higher
• Memory: 8MB minimum
• Hard Disk space: 6MB minimum
• USB port must be standard equipment
Install the required software as follows.
1 Turn on your Macintosh.
2 Insert the CD-ROM (S-SW14)
into your Mac’s CD-ROM drive.
3 Double click the [CD-ROM (S-
SW14)].
The title screen will appear on your
desktop.
Software Provided
System Requirements
We recommend using the AC Adapter D-AC8 when connecting your
camera to your PC. Your image data could be corrupted if your
battery run out during image transfer.
Installing the Software

Pentax OPTIO S4 Specifications

Operating Environment

operating temperatures	32˚ to 104˚F (0˚ to 40˚ C)
camera casing	Aluminum alloy

Power

power source	Rechargeable lithium-ion D-LI8 battery, AC adaptor kit (optional)

Camera

effective pixels	4.0 megapixels
total pixels	4.23 megapixels
color depth	10 bit x 3 colors

Lens and Focus System

focal length	5.8mm- 17.4mm
35mm equivalent	35mm-105mm
aperture range	f2.6- f4.8

Viewfinder and Monitor

optical viewfinder	Actual Image zoom viewfinder
lcd monitor	1.6 inch, TFT color LCD with Histogram Display
lcd resolution	84K Pixels

Weight and Dimensions

dimensions	3.3 x 2.0 x 0.8 Inches (83 x 52 x 20mm)
weight without battery and SD card	3.5 oz (98g)
weight loaded and ready	4.1 oz (115g)
