Pepperl+Fuchs BTC14N-GP-TS20-DP-N0 User Manual

Box Thin Client for Industrial Applications
Installation
2019-12
23
LED Indicator
DisplayPort
TM
Figure 3.18
No. Type Description
Green LED Off: no connection
Flashing: active data
On: connection
Yellow LED Off: 10 Mbit/s connection
Flashing: 100 Mbit/s connection
On: 1 Gbit/s connection
Pin Type Description
Input/out-
put
1 ML_Lane0+ DP Data 0+ Output
2 GND Ground -
3 ML_Lane0- DP Data 0- Output
4 ML_Lane1+ DP Data 1+ Output
5 GND Ground -
6 ML_Lane1- DP Data 1- Output
7 ML_Lane2+ DP Data 2+ Output
8 GND Ground -
9 ML_Lane2- DP Data 2- Output
10 ML_Lane3+ DP Data 3+ Output
11 GND Ground -
12 ML_Lane3- DP Data 3- Output
13 CONFIG1
CAD
Cable-adapter detection Input
14 CONFIG2 Ground (pull down) -
15 AUX_CH+ Auxiliary channel+ Input/output
16 GND Ground -
17 AUX_CH- Auxiliary channel- Input/output
18 HPD Hot Plug Detect Input
19 GND Ground -
20 DP_PWR +3.3 V (fused) Output
1
2
1
2
19
20
