Box Thin Client for Industrial Applications

Installation

USB Ports

Figure 3.19 USB 2.0

Figure 3.20 USB 3.0

Pin Type Description

1 USB_P5V_-

fused (A)

+5 V (fused)

2 USB_D0M

(I/O)

Data-

3 USB_D0P

(I/O)

Data+

4 USB_GND GND

Pin Type Description

Input/out-

put

1 VBUS + 5 V (fused) Output

2 D- Data channel USB 2.0 Input/output

3 D+ Data channel USB 2.0 Input/output

4 GND Ground -

5 RX- Data channel USB 3.0 Input

6 RX+ Data channel USB 3.0 Input

7 GND Ground -

8 TX- Data channel USB 3.0 Output

9 TX+ Data channel USB 3.0 Output

1234

98765
