Pepperl+Fuchs HD2 Series User Manual

Compact Fieldbus Power Hub,Generic Interface
Thermal Dissipation
2014-10
23
Thermal Dissipation of HCD2-FBPS-1.23.500, Including Motherboard
HCD2-FBPS-1.23.500
HCD2-FBPS-1.23.500
24 V
19.2 V
35 V
24 V
19.2 V
35 V
3
2,5
2
1,5
1
0,5
Disspation in [W]
Segment current in [mA]
Power Dissipation in SIMPLEX Configuration per Segment
Power Dissipation in REDUNDANT Configuration per Segment
0 500100
Disspation in [W]
Segment current in [mA]
200 300 400
3
2,5
2
1,5
1
0,5
0 500100 200 300 400
