Compact Fieldbus Power Hub,Generic Interface
Safety
1.5 Delivery, Transport and Storage
Check the packaging and contents for damage.
Check if you have received every item and if the items received are the ones you ordered.
Keep the original packaging. Always store and transport the device in the original packaging.
Always store the device in a clean and dry environment. The permitted storage temperature
(see data sheet) must be considered.
1.6 Marking
Motherboards
Fieldbus Power Hubs
Diagnostic Modules
For marking information of the diagnostic modules refer to the instructions or manuals of the
respective diagnostic module used.
1.7 Intended Use
The FieldConnex
®
compact Power Hub is intended to power 8 FOUNDATION Fieldbus H1
segments in redundant mode according to IEC 61158-2.
MBHC-FB-8R*
Pepperl+Fuchs GmbH
Fieldbus Power Hub 
Motherboard
TÜV 10 ATEX 555761X
II 3G Ex nA IIC T4 Gc
IECEx TUN 13.0037X
Ex nA IIC T4 Gc
HCD2-FBPS-1.500
Pepperl+Fuchs GmbH
Fieldbus Power Hub
Galvanically Isolated Fieldbus Power Supply
TÜV 10 ATEX 555761X
II 3G Ex nA IIC T4 Gc
IECEx TUN 13.0037X
Ex nA IIC T4 Gc
HCD2-FBPS-1.23.500
Pepperl+Fuchs GmbH
Fieldbus Power Hub
Galvanically Isolated Fieldbus Power Supply
TÜV 10 ATEX 555761X
II 3G Ex nA IIC T4 Gc
IECEx TUN 13.0037X
Ex nA IIC T4 Gc
