6.1 Isolated Barriers Dismounting
Dismounting the Isolated Barrier from the Termination Board
1.
Pull the Quick Lok bar (1) into the upper position.
2. Carefully pull out the device from the contacts and locking elements.
Figure 6.1 Dismounting of an H-System isolated barrier
1 Quick Lok Bar
2 Coding pins
3 Adjustment pins
1
2
3
3
