2023-03
42
H-System – Isolated Barriers and Termination Boards
Technical Specifications
Model Number description Generic Termination Boards
Hi –
–
–TB
–
–
1 System
2 Housing type
3 Device type
4 Number of slots
12 Version
11 Fault monitoring
10 Power supply
9 Field side connection
8 Termination board channel configuration
5 Control side connection
7 Number of pins per module on the field side
6 Number of pins per module on the control side
Position 1 Hi H-System
Position 2 C for HiC devices, housing width 12.5 mm
Position 3 TB Termination board
Position 4 08 8 slots
16 16 slots
32 32 slots
Position 5 SCT Screw terminals
SDC Sub-D connector
SPT Spring terminals
Position 6 2 2 pins per module
4 4 pins per module
8 8 pins per module
9 9 pins per module
Position 7 2 2 pins per module
4 4 pins per module
8 8 pins per module
9 9 pins per module
Position 8 A Alternative channel configuration
C Consecutive channel configuration
S Channel configuration suitable for signal splitter
Position 9 PL Pluggable screw terminals
SC Screw terminals
SP Spring terminals
Position 10 D Daisychainable power supply
N Without power supply
R Redundant power supply
S Single power supply
