2.2.1 Color Coding of the Isolated Barriers
The color coding of the devices has the following meaning:
Figure 2.3 Color identification of devices
1 Digital input – switch amplifier with relay output
2 Digital input – switch amplifier with transistor output
3 Digital input – switch amplifier with transistor output and active voltage output for safety
sensors SN, S1N
4 Digital output – solenoid driver, relay module
5 Analog input – transmitter power supply, converter, repeater
6 Temperature input – temperature converter
7 Analog output – current driver
8 Universal input/output – universal barrier
