KF Device Housing
Figure 2.4 KF device housing (20 mm)
Used for high channel density
• Compact 20 mm housing
• Packing density from 5 mm per channel
Figure 2.5 KF device housing (40 mm)
Used for applications with high functionality
• Digital devices monitor speed, direction of rotation, slip, flow rates and time.
• Analog devices monitor transmitter signals, temperature signals and load cells.
• Configured using keypad or PACTware
TM
software, see also manual "Installation
and Configuration Device Type Manager (DTM)"
• AC/DC wide range supply available
