Functional Safety KFD2-CD-(Ex)1.32-**
Product Description
2018-11
7
2 Product Description
2.1 Function
KFD2-CD-1.32
This signal conditioner provides the galvanic isolation between field circuits and control
circuits.
The device supplies 2-wire transmitters.
The device transfers a current signal from the control side to I/P converters, electrical valves
and positioners located in the field side.
The device is mounted on a 35 mm DIN mounting rail according to EN 60715.
KFD2-CD-Ex1.32-**
This isolated barrier is used for intrinsic safety applications.
The device supplies 2-wire transmitters.
The device transfers a voltage or a current signal from the non-hazardous area to
I/P converters, electrical valves and positioners located in the hazardous area.
The device is designed to provide various inputs and outputs of voltage and current.
The device is mounted on a 35 mm DIN mounting rail according to EN 60715.
2.2 Interfaces
The device has the following interfaces.
• Safety relevant interfaces:
• Non-safety relevant interfaces: none
Input, output KFD2-CD-1.32
KFD2-CD-Ex1.32-0, KFD2-CD-Ex1.32-1, KFD2-CD-Ex1.32-3,
KFD2-CD-Ex1.32-6, KFD2-CD-Ex1.32-10, KFD2-CD-Ex1.32-12,
KFD2-CD-Ex1.32-13, KFD2-CD-Ex1.32-15, KFD2-CD-Ex1.32-21
Note!
For corresponding connections see datasheet.
