Pepperl+Fuchs WCS3B-LS610 - Page 61

WCS* Read Head Position Encoding System
PROFINET Interface (LS6xx*)
2020-01
61
Response
Bit no.
Content
Function
Byte 1
Status
1 ERR Error message, see error codes ERR00 – ERR07
2 OUT Read head partially outside the code rail. No valid posi-
tion available.
3 OUTALL Read head completely outside the code rail.
4 DB Diagnostic bit. Read head dirty.
5 SST Speed status
6 Reserved -
7 Reserved -
8 Reserved -
