Z-System – Zener Barriers
Installation
2016-03
15
3 Installation
3.1 DIN Mounting Rail
The devices are mounted on a 35 mm DIN mounting rail according to EN 60715.
Figure 3.1 Example: DIN mounting rail (35 mm x 15 mm)
Z-System – Zener Barriers
