Pepperl+Fuchs Z-System - Order Designation

2016-03
28
Z-System – Zener Barriers
Technical Specifications
6.3 Order Designation
Z .
1 System
2 Polarity
3 Version
4 Special function,
if available
Position 1 Z Z-System
Position 2 0 DC device with positive polarity
7 DC device with positive polarity
8 DC device with negative polarity
9 AC device
Position 4 1K With increased nominal resistance 1 k
CL With current limiting
F With replaceable back-up fuse
H High power version
R With internal measuring resistor
