Z-System – Zener Barriers
Technical Specifications
2016-03
27
Accessories
Mounting Accessories
For the different grounding options special accessories are needed.
See chapter 3.3.1.
Further Accessories
• Empty housing zener barrier Z799
This zener barrier is an empty housing. This device will be used as a dummy,
to reserve place and wiring for future expansions.
• Label carrier ZH-Z.BT
• Label ZH-ES/LB with labeling field 29 mm x 8 mm
Equipotential bonding via
DIN mounting rail
•Terminal block USLKG5
• 35 mm DIN mounting rail according to EN 60715
Group grounding through
insulated mounting
•Terminal block USLKG5
• 35 mm DIN mounting rail according to EN 60715
•Adapter ZH-Z.AB/NS
Individual grounding
through insulated
mounting
• Single socket ZH-Z.ES
• 35 mm DIN mounting rail according to EN 60715
•Adapter ZH-Z.AB/SS
• Grounding bar ZH-Z.NLS-Cu3/10
• Grounding bar feed ZH-Z.LL
• Spacer ZH-Z.AR.125
• Terminal ZH-Z.AK16
Note!
For more information see the corresponding datasheets.
