Peqlab Precellys 24 - Technical Data

Short protocol Homogeniser Precellys
®
24 / 24-Dual
PEQLAB_v0314_E
18
Technical Data
Electric properties
Voltage range 240 V/50 Hz or 120 V/60 Hz (European or US standard)
Power input < 1 kVA
Specification of fuses 5 x 20 – T 10 A – H 250 V
Classification Class I
Physical properties
Width 290 mm
Height 370 mm at closed lid, 600 mm at open lid
Depth 375 mm
Weight 29.8 kg
Generation of noise < 70 dB
Environmental conditions
Temperature 15 - 30 °C
Humidity 15 - 85 % HR
Altitude (above sea level) < 2000 m
Programmable parameters
Storable programs 5
Precellys
®
24: 2500 rpm (Low Speed Program)* and
4000* - 6800 rpm, in steps of 100 rpm
Agitation speed
Precellys
®
24-Dual: 2500 rpm (Low Speed Program)** and
4000** - 6500 rpm, in steps of 100 rpm
Duration of an agitation interval 5 - 90 s, in steps of 1 s (see 'combinable parameters...')
Repetition of an agitation interval 1 - 3
Pause between agitation intervals 5 - 120 s, in steps of 1 s (see 'combinable parameters...')
Precellys
®
24: 2 or 5 min (see 'combinable parameters...'),
disengageable***
Rest time between two consecutive runs
(refractory period)
Precellys
®
24-Dual: none***
Sample capacity
Sample number/run Precellys
®
24:
Precellys
®
24-Dual:
up to 24 x 2 ml tubes
up to 12 x 2 ml or up to 6 x 7 ml tubes
Maximal sample volume 0.35 ml in 0.5 ml tubes
1.4 ml in 2 ml tubes
5 ml in 7 ml tubes
*from firmware version 4.1 (12/2011) on, until then 5000 – 6800 rpm, in steps of 100 rpm
**from firmware version 4.1 (12/2011) on, until then 5000 – 6500 rpm, in steps of 100 rpm
***from firmware version 4.1 (12/2011) on, until then refractory periods of 2 or 5 min (see 'Combinable parameters/Refractory period')
THE ACTUAL FIRMWARE VERSION OF THE SYSTEM IS DISPLAYED WHEN PRESSING 'CANCEL' FOR 10 SEC AFTER SWITCHING ON THE UNIT.
