Perel CCTVSETW1 - Camera Installation; Required Tools; Guidelines; Setting up the Camera

CCTVSETW1
V. 02 – 07/01/2014 6 ©Velleman nv
• Keep this manual for future reference.
5. Overview
Refer to the illustrations on page 2 of this manual.
Monitor (back panel)
1
antenna slot
2
reset button
3
power on/off
4
SD slot
5
AC power connection
6
camera stand
Cradle
7
power dock
8
RJ45 network connection
9
AC power connection
Camera (front)
10
power status
11
link status
12
light sensor
Camera (back)
13
antenna connector
14
microphone
15
power cable
16
power/pair button
6. Camera Installation
Required tools
• electric drill
• 5 mm masonry drill bit
• 15 mm masonry drill bit
• no. 2 Philips screwdriver
Guidelines
• It is recommended to test the camera before mounting it on its final spot.
• Mount the camera at about 2.5 m from the floor.
• Avoid positioning the camera so that it is facing directly at the sun as this will impair the picture
quality viewed.
• Avoid pointing the camera lens directly through clear glass as the night vision LEDs will cause a
blurred image at night.
• Avoid pointing the camera directly at any bushes, tree branches or moving objects that might
naturally move due to winds. This is also because if you need to use the motion detection feature in
the PC software to record movement the software might record unnecessarily.
Setting up the camera
See image C on page 4.
1. Extend the antenna.
2. Connect the power adapter to the camera and then to a wall outlet.
3. Plug the power adapter into a wall outlet.
Setting up the monitor
See image D on page 4.
