1. Phillips screw driver 2. Adjustable wrench 3. PTFE Tape
TOOLS REQUIRED
CONTENTS
1 Pump Body ......................... 1
2 Handle ................................. 1
3 Discharge Spout ................. 1
4 Retainer Nut ........................ 1
5 Machine Screw ................... 2
6 Lock Nut ............................2
7 Washer ...............................4
8 Suction Tube w/Strainer ....1
9 Suction Tube Extension .....1
10 Base Suction Tube .............1
No. Description Qty. No. Description Qty.
1
2
3
4
5
6
7
8
9
1
0
• Provide positive shut-off valves on all xed fuel supplies. Fuel lines must be made of
steel piping, leak-free and securely fastened.
• Adequate ventilation is essential! Clean up all spills immediately when pumping or
handling ammable liquids.
• ABSOLUTELY NO SMOKING!
• DO NOT use torches or apply re or ames to this pump, pump components or any
containers used with this pump.
• Be sure that the discharge line is secure before pumping. An insecure discharge line
may slide, possibly causing personal injury and/or damage to property.
• Over tightening non-metallic ttings will strip threads. Once tting is “hand tight” turn one
more full rotation, this is usually enough to prevent leaking. Thread sealant can be used
on all threaded joints, including the delivery spout.
•
Before each use, check hoses for weak or worn spots. Check the security of all connections.
• Occasionally inspect the pump and components, performing routine maintenance
when required.
•
Dispel all liquids from the pump and components before performing routine maintenance.
IMPORTANT SAFETY INFORMATION
WARNING: AFTER USE, STORE ALL PUMPS USED FOR TRANSFERRING HAZ-
ARDOUS, FLAMMABLE OR COMBUSTIBLE LIQUIDS IN A WELL-VENTILATED AREA.
To Next Page
