10
KNOW THE BENCH GRINDER (Fig. 3)
The machine is intended for sharpening tools such as chisels, planer blades,
scissors, etc., and for removing rust or corrosion.
WARNING: Do not allow familiarity with the grinder to cause carelessness.
Remember that a careless fraction of a second is sufficient enough to inflict
severe injury.
WARNING: Remove the bench grinder from the carton and examine it care-
fully. Do not dispose of carton or any packaging material until all parts are
examined.
WARNING: To avoid injury, ALWAYS
turn the tool off and disconnect the
grinder from the power outlet before
installing or changing the grinding
wheel.
MOUNTING SAFETY SHIELD
ASSEMBLY(Fig.4)
1. Turn off and unplug the grinder
Fig. 4
Fig. 3
1. On/Off switch with key
2. Worklight switch
3. Coolant tray
4. Right tool
tool
rest
5. Left rest (grooved)
6. Left safety shield (w/
magnifier)
7. Right safety shield
8. Left wheel guard
9. Worklight
10. Grinding wheel
11. Right wheel guard
9
11
10
4
3
5
8
6
7
1
2
H
C
I
J
Customer Se
r
vice: 1
-866-858-2664
Z19
8-inch BENCH GRINDER
wi
t
h d
u
a
l
w
o
r
k
li
g
h
t
s
DESCRIPTION
ASSEMBLY AND ADJUSTMENTS
