Performax px12 - Parts List

Performax px12
31 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
29
WARNING: When servicing, use only original equipment replacement parts. The
use of any other parts may create a safety hazard or cause damage to the oscillating tool.
Any attempt to repair or replace electrical parts on this oscillating tool may create a safety
hazard unless repairs are performed by a qualified technician. For more information, call
the Toll-free Helpline, at 1-866-349-8665.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
1070060003
Battery pack
1
2
1180060006
Contact plate
1
3
3010170001
Housing
1
4
2030090006
Retaining ring
1
5
1200190008
Winding displacement
1
6
1130050006
Protection circuit board
1
7
3110010024
Decorative plate for switch
1
8
3120010023
"" Button
1
9
3120010022
"+" Button
1
10
1130030003
Control circuit board
1
11
1220050003
LED light
1
12
3160060011
Transparent cover
1
13
3120010021
Main switch button
1
14
3160060004
LED transparent cover
1
15
4030010006
Screw ST2.2×6.5
2
16
1039040001
Motor
1
17
3150090007
Motor flange
1
18
4040030002
Spring washer M3
2
19
4020010028
Screw M3×8
2
20
2010230005
Active plate
1
