Illustration 62 g06523817
(6) Hand priming pump
(7) In-line priming pump
(8) Electrical priming pump
(9) Fuel transfer pump with hand priming
Illustration 63 g06523835
(10) Connector bolt (11) Fuel return line (12) Connector bolt
Hand Priming Pump 6
To identify the hand priming pump, refer to illustration
62 .
1. Ensure that fuel valve (2) for the fuel filter that has
an element is in the ON position. Refer to
illustration 59 .
82
SEBU8311-09
Maintenance Section
Fuel System - Prime
