Four Cylinder engine
Illustration 14 g03886691
(1) High-pressure line
(2) High-pressure line
(3) High-pressure line
(4) High-pressure line
(5) High-pressure fuel manifold (rail)
(6) High-pressure line
(7) Fuel transfer line that is high pressure
18
SEBU9075-03
Safety Section
High Pressure Fuel Lines
