Illustration 51 g03331704
Typical example
3. Remove filter element (5) and remove O ring seal
(6) and discard.
Note: Ensure that all parts are clean and free from
dirt.
4. Install a new O ring seal (6) onto the cap (2) and
install a new filter element (5) into the cap (2).
5. Install cap assembly into the main body (1).
Tighten the cap assembly to 10 N·m (7 lb ft).
6. Install hose (4) and clip (3). Remove the container
and clean away any split fluid.
i06709044
Engine - Clean
Personal injury or death can result from high
voltage.
Moisture can create paths of electrical
conductivity.
Make sure that the electrical system is OFF. Lock
out the starting controls and tag the controls ““DO
NOT OPERATE”” .
NOTICE
Accumulated grease and oil on an engine is a fire
hazard. Keep the engine clean. Remove debris and
fluid spills whenever a significant quantity accumu-
lates on the engine.
Periodic cleaning of the engine is recommended.
Steam cleaning the engine will remove accumulated
oil and grease. A clean engine provides the following
benefits:
• Easy detection of fluid leaks
• Maximum heat transfer characteristics
• Ease of maintenance
Note: Caution must be used to prevent electrical
components from being damaged by excessive water
when the engine is cleaned. Pressure washers and
steam cleaners should not be directed at any
electrical connectors or the junction of cables into the
rear of the connectors. Avoid electrical components
such as the alternator, the starter, and the ECM.
Protect the fuel injection pump from fluids to wash the
engine.
Ensure that care is taken that the safety labels,
emission label, and any information labels are not
removed during engine cleaning.
Ensure that care is taken that the safety labels,
emission label, and all other information labels are
not removed during engine cleaning.
88
SEBU9075-03
Maintenance Section
Engine - Clean
