72 KENR9126
Troubleshooting Section
(Table 20, cont
d)
CDL Code Description
3rd Party
Device
J1939
Code
Flash
Code
0100-10
Engine Oil Pressure Sensor abnormal rate of change
100-10 157
0110-03
Engine Coolant Temperature Sensor voltage above normal
110-03 168
0110-04
Engine Coolant Temperature Sensor voltage below normal
110-04 168
0127-03
Transmission Oil Pressure open/short to +batt
127-03 311
0127-04 Transmission Oil Pressure short to ground 127-04 311
0168-00 Electrical System Voltage high 168-00 511
0168-01 Electrical System Voltage low 168-01 511
0168-02 Electrical System Voltage erratic, intermittent, or incorrect 168-02 511
0172-03 Intake Manifold Air Temperature Sensor voltage above normal 105-03 133
0172-04 Intake Manifold Air Temperature Sensor voltage below normal 105-04 133
0174-03 Fuel Te mperature open/short to +batt 174-03 165
0174-04 Fuel Temperature short to ground 174-04 165
0177-03
Transmission Oil Temperature open/short to +batt
177-03 312
0177-04 Transmission Oil Temperature short to ground 177-04 312
0190-08 Engine Speed Sensor abnormal frequency, pulse w idth, or period 190-08 141
0253-02 Personality Module erratic, intermittent, or incorrect 234-02 416
0261-11 Engine Timing Offset fault 637-11 143
0262-03
5Vo
lt Sensor DC Power Supply voltage above normal 3509-03 516
0262-04
5 Volt Sensor DC Power Supply voltage below normal
3509-04 516
0268-02 Programmed Parameter Fault erratic, intermittent, or incorrect 1111-02 527
0342-08
Secondary Engine Speed Sensor abnormal frequency, pulse width,
or period
723-08 142
0526-05 Turbo Wastegate Drive current below normal 1188-05 177
0526-06 Turbo Wastegate Drive c urrent above normal 1188-06 177
0526-07 Turbo Wastegate Drive not responding properly 1188-07 177
0535-03 Exhaust Gas Temperature short to ground 173-03 185
0535-04 Exhaust Gas Temperature open/short to +batt 173-04 185
0774-08
Secondary Throttle Position Sensor abnormal frequency, pulse width,
or period
29-08 155
0774-13 Secondary Throttle Position Sensor incorrect calibration 29-13 155
0897-05 Glow Plug Start Aid Relay 2 current below normal 1084-05
-
0897-06 Glow Plug Start Aid Relay 2 current above normal 1084-06
-
1779-05 Fuel Rail #1 Pressure Valve Solenoid current below normal
-
162
1779-06 Fuel Rail #1 Pressure Valve Solenoid current above normal
-
162
1785-03 Intake Manifold Pressure Sensor voltage above normal 102-03 197
1785-04 Intake Manifold Pressure Sensor voltage below normal 102-04 197
1785-10
Intake Manifold Pressure Sensor abnormal rate of c hange
102-10 197
1797-03
Fuel Rail Pressure Sensor voltage above normal
157-03 159
(continued)
