Only one bolt size fits your TV.
M6M4 M8
Bolt length:Verify adequate thread engagement with bolts or bolts/spacers combination.
We recommend thread engagement by at least 5 turns.
-Too short will not hold the TV.
-Too long will damage the TV.
Too Short
Too Long
Correct Correct
Select TV Bolts
Note: If necessary, the spacers can be used in multi-layer. If the installation fails
after trying various methods, please contact customer service at
support@perlegear.com
CAUTION: Ensure the TV brackets
10 are EQUALLY CENTERED on your
TV and securely fastened in place.
10
UP
Note:
Keep the arrow up.
TV9 x4
φ8.5x18x10mm
TV10 x4
φ8.5x18x22mm
TV8 x8
φ8.5x18x2.5mm
Spacers
[if needed]
10
To Next Page
