Perlegear PGTVMC06 - Mounting Options for Bump;Inset Holes

Spacers may be necessary for 2 holes ONLY.
Option C (For TV with A “Bump”)
Option D
For cable interference or inset holes, use spacers [TV8/TV9/TV10] to
create extra space between the TV and TV brackets
(If needed)
10
10
TV1(01)
/TV2/TV4
TV6
TV8/TV9/TV10
TV1(02)/TV3/TV5
TV8/TV9/TV10
TV1(02)/TV3/TV5
TV6
TV6
12
Alternate Spacer Setups
Alternate Spacer Setups
TV7
TV7
