Perlegear PGTVMC06 - Step 12: Adjustments; TV Tilt Adjustment; TV Level Adjustment; Wire Management

3/8 in.(10mm)
Wrench
12-1 Tilt Adjustment
12-2 Level Adjustment
1. Slightly loosen the both tilt nuts [L].
2. Adjust TV to your desired tilt angle.
3. Tighten the both tilt nuts [L] to secure the TV in place.
L
12-3 Manage the Wires
Step 12
Adjustments
16
1. Slightly loosen the both nuts [S] using wrench.
2. Level the TV.
3. Retightent both nuts [S] to secure the TV in place.
S
3/8 in.(10mm)
Wrench
