Perlegear PGTVMC06 - Step 1: Assemble the Base; Connecting Base Tubes

Step 1
Assemble the Base
Secure the short square tubes [03] and long square tubes [02] to the tube
connector [01] using bolts [B] and Allen key [F] .
5/32 in.(4mm)
Small Allen Key
Tube Connector
B
5/32In.(4mm)
Small Allen Key
F
x1
x2
x2
x8
Long Square
Tube
x1
Short Square
Tube
M6x12mm
Bolt
01
02
03
3
01
03
02
B
F
Front Side
Back Side
Small Allen Key
