Perlegear PGTVS16 - Page 4

Supplied Parts and Hardware for Step 3
(D) x2
φ8.5xφ20x1.5
Washer
(G) x1
13/64 in.(5mm)
Large Allen Key
(A) x2
M8x36mm
Bolt
(F) x2
Wire Clip
M6
[TV3] x4
M6 x 15mm
Bolt
[TV4] x4
M6 x 35mm
Bolt
M8
[TV5] x4
M8 x 15mm
Bolt
[TV6] x4
M8 x 35mm
Bolt
[06] Washer
If necessary
[07] Spacers
If necessary
Note: The washer and spacers are shown
in actual size
[TV9] x4
22mm
[TV8] x4
2.5mm
[TV7] x4
M4/M6 Washer
(04) x1
Faceplate
01 02 03 04 05 06 07 08 09
