Perlesmith PSLF7 - Page 4

06
x1
13/64 in.(5mm) Allen Key
Arm Assembly/Wall Plate
05
x1
03
x2
Arm Extension
(X4)
M6X10mm
B1
Bolt
B2
(X4)
M6
Washer
Supplied Parts and Hardware for Step 2
04
x2
TV Bracket
M6
M8
Note: The bolts are shown in accordance with the actual size
M6 x 15mm
[D1] x4
M6 x 35mm
[D2] x4
[Only one bolt size fits your TV]
TV Bolts
09
M8 x 50mm
[E3] x4
M8 x 25mm
[E1] x4
M8 x 35mm
[E2] x4
03
01
x1
Front Support
