Step 1 Before TV Bracket Installation
For Flat screen TV
For Curved TV/Extra Space
Step 2 Install TV Bracket
3
D1
E1
B1
B2/C
D22/F
B1
Manual Only!
Manual Only!
Manual Only!
Hand thread screws into the threaded inserts
on the back of your TV to determine which
screw diameter (M4, M6, or M8) to use
When attaching brackets to the flat screen, be careful not to over tighten screws and be
sure that screws do not bottom out in the mounting holes.
Too Short Too Long Correct Correct
02
02
E2
To Next Page
