Support
Pillar
Foot pads
Plastic cover
•Carefully open the carton, remove contents and lay out on cardbard or other protective
surface to avoid damage.
•Check to assure that all components were received undamaged. Do not use damaged or
defective parts.lf you require replacement parts, contact customer service at
supportus@perlesmith.com
•Carefully read all instructions before attempting installation.
UNPACKING INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
•Install and operate this product with care. Please read this instruction before beginning the
installation, and carefully follow all instructions contained herein. Use proper tools during
installation.
•Do not use this product for any purpose or in any configuration not explicitly specified in
this instruction. We hereby disclaim any liability for injury or damage arising from incorrect
assembly, incorrect mounting, or incorrect use of this product.
Step 1 Connecting the Support Pillar(P) to Tempered Glass(O)
M6x25 Bolt
Tempered
Glass
Gasket
Place foot pads(W) on the bottom of the
tempered glass base(O) at the corners
1.1
(V)
•
If you do not understand the instructions or have any concerns or questions, please contact
customer service at
supportus@perlesmith.com
or call a qualified installation contractor.
Wrench
To Next Page
