Replacement Parts
MODEL NOS. HC24RS HC24FS HC24WS
Item Description Part Numbers
1 Light switch, Rocker 63303 63303 63303
2 Door Switch, Plungers 63711 63711 63711
3 Light Assembly 63716 63716 63716
4 Light Bulb - Replacement 63716-1 63716-1 63716-1
5 Condenser/Evaporator Fan 65253 65253 65253
6 Evaporator Fan Guard 65254 65254 65254
7 Temperature Control 61282 61282 61282
8 Power Cord 65470 65470 65470
9 Wire Harness, Machine Compartment 65758 N/A 65785
10 Wire Harness, Evaporator Compartment 65759 65475 65759
11 Wire Harness, Evaporator Fan Motor N/A 65271 N/A
12 Wire Harness, 6 Hour Defrost N/A 61959 N/A
13 Wire Harness, Relay N/A 65476 N/A
14 Wire Harness, Light to Door Switch N/A 65934 N/A
15 Defrost Terminator N/A 57676 N/A
16 Solid State Controller N/A 57466 N/A
17 Time Delay Relay N/A 63794 N/A
18 Switch Monetary N/A C31659 N/A
19 Compressor w/Electricals 63778 63779 63778
20 Drier 63719 63719 63719
21 Fin Coil, Evaporator 65251 65251 65251
22 Fin Coil, Condenser 65252 65252 65252
23 L&S Line Assembly 65407 65407 65407
24 Hot Gas Solenoid Valve (Complete) N/A 63717 N/A
25 Replacement Door (Configured) RD-HC24 RD-HC24 RD-HC24
26 Gasket, Door 66237-7 66237-7 66237-7
27 Plunger Bracket for Door Switch 63948-1 63948-1 63948-1
28 Hinge Kit, Left Hand 67052L 67052L 67052L
29 Hinge Kit, Right Hand 67052R 67052R 67052R
30 Lock Kit, Left Hand 67054L 67054L 67054L
31 Lock Kit, Right Hand 67054R 67054R 67054R
32 Lock, Polished Brass (Lock Only) 67109PB 67109PB 67109PB
33 Handle, Door, Long SS 65305-1 65305-1 65305-1
34 Handle, Door, Short SS 65305-2 65305-2 65305-2
35 Handle, Door, Classic 6" Pull C31409-1 C31409-1 C31409-1
36 Handle, Door, Pull Tab 65609-3 65609-3 65609-3
37 Replacement Door Overlay (Configured) RO-CC RO-CC RO-CC
38 Replacement Shelving (Configured) RS-24 RS-24 RS-24
39 Leveling Leg 63728 63728 63728
