12
Operation & Installation Manual
Signature Series Beer Dispensers (HP15, HP24 and HP48 models)
Figure 10- Toe Plate Wood Overlay Template for HP15TS
7 1/16"
3/4"
1"
4 1/8"
C
FRONT VIEW
11/16"
17/64"
R
1/4"
1 29/32"
B
B
D
REAR VIEW
NOTE: ALL INTERNAL RADII ARE 1/8IN UNLESS OTHERWISE SPECIFIED
1/32"
9/32"
SECTION B-B
SCALE 1 : 2
1"
5/16"
TYPICAL
1/4"
TYPICAL
3"
TYPICAL
3/16"
TYPICAL
29/32"
DETAIL C
SCALE 1 : 2
3/8"
3/8"
11/16"
1"
3/32"
5/32"
43/64"
29/64"
7/64"
DETAIL D
SCALE 1 : 1
3/8"
1/2"
7/8"
1/8"
3/32"
9/32"
9/32"
7/64" 7/64"
1/4"
METAL CLIP REQUIRED FOR SNAP IN RETAINER THAT
ASSEMBLES GRILL TO THE UNIT. THIS CLIP MUST BE
SCREWED TO THE GRILL USING THE FEATURES SHOWN
IN DETAIL VIEW "D"
1/32"
THICK (20GA)
GALVANIZED OR
STAINLESS STEEL
RECOMMENDED
2
2
B
A
3
C
B
A
1
C
1
3
SW
THIS DOCUMENT / PUBLICATION / SOFTWARE / DRAWING CONTAINS PROPRIETARY INFORMATION WHICH IS THE PROPERTY OF THE PERLICK CORPORATION. IT MAY NOT BE REPRODUCED OR TRANSMITTED IN ANY FORM, ELECTRONIC OR MECHANICAL,
INCLUDING PHOTOCOPYING, RECORDING, OR USED IN ANYINFORMATION STORAGE, TRANSMISSION, OR RETRIEVAL SYSTEM, WITHOUT WRITTEN PERMISSION FROM THE PERLICK CORPORATION. COPYRIGHT 2001 PERLICK CORPORATION. ALL RIGHTS RESERVED.
SHEET 3 OF 4
SCALE =
TITLE:
MATERIAL:
DATE
SIGNATURES
DESIGNED
DRAWN
CHECKED
PURCHASE REC.:
REFERENCE:
UNLESS OTHERWISE SPECIFIED:
PART NO.
DWG NO.
REVISIONS
GRILL, WOOD
15IN
WOOD GRILL
WOOD GRILL, 15IN
NAH
4/23/2008
NAH
4/23/2008
4/23/2008
WOOD
QTY.:
FINISH:
BREAK SHARP EDGES - 015 X 45°.
RADIUS SHARP FILLETS - .015 TO .031
DIMENSIONS ARE IN INCHES
TOLERANCES:
.X= ,
.XX = ,
.XXX = ,
ANGULAR: ±1.0°, FRACTIONS: ±1/16
J:\Dwg\_ Assembly\HHC GEN2\HHC GEN2 24IN RESIDENTIAL\Wood Grill.slddrw
